Technical Data – AC Compressor Mount

Parameter	Specification
Rubber	Natural or Chloroprene
Temp Range	-40°C to +120°C
Bonding	No delamination under shear
Quality System	IATF16949
Inspection	100% factory inspection
Custom Lead Time	60-90 working days

Eliminating the "A/C Shake"

When the A/C compressor kicks in, its piston motion creates a noticeable vibration that can travel through the engine block and into the cabin. Our AC Compressor Mount dampens that pulsation so that you barely feel the compressor cycling. This is especially important for hybrid and electric vehicles where the cabin is already quiet – any extra vibration becomes highly noticeable. We have engineered this mount for over 20 years, and today it is used by leading Chinese automakers to improve their NVH scores.

Oil-Resistant and Heat-Stable Rubber

The compressor operates near the engine, exposed to heat, oil, and constant movement. We use chloroprene or high-grade natural rubber with excellent oil and heat resistance (-40°C to +120°C). The metal bracket is phosphated, and the rubber-to-metal bond is strong enough to withstand shear forces during belt tension changes. Our AC Compressor Mount is 100% inspected for hardness, bond integrity, and dimensional accuracy. We run cyclic fatigue tests to simulate years of use, ensuring no cracking or loosening occurs.

Custom Mounting Configurations

We can tailor the AC Compressor Mount to your compressor bracket design – just provide the bracket dimensions and load data. Standard mounts ship in 30 working days; custom versions take 60-90 days. MOQ is RMB 50,000, and we offer one free sample from our standard catalog (freight collect). Payment is 70% in advance, 20% at port, 10% retention. We also offer engineering support to help you optimize the mount's stiffness for your specific compressor.
